National Item Identification Number

00-070-4614

National Stock Number

Item Name

PIN,STRAIGHT,HEADLESS

Federal Supply Class

5315

Referenced on: http://gasturbinegenerators.tpub.com//TM-1-2840-254-23P/css/TM-1-2840-254-23P_190.htm
Referenced on: http://gasturbinegenerators.tpub.com//TM-1-2840-254-23P/css/TM-1-2840-254-23P_361.htm

Description

A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.

Commercial and Government Entity Code (Supplier Data)

---

73030

---

---

NSN (National Stock Number) 5315-00-070-4614, 5315000704614 NIIN (National Identification Number) 00-070-4614, 000704614

Part Numbers (Reference Numbers)

513048

Required Categories

MATERIAL
SURFACE TREATMENT
HARDNESS RATING
FIRST END STYLE
SECOND END RELATI

Required Description

STEEL OVERALL
PASSIVATE OVERALL
70.0 ROCKWELL B MINIMUM AND
100.0 ROCKWELL B
