National Item Identification Number

00-807-7957

National Stock Number

Item Name

PIN,STRAIGHT,HEADLESS

Federal Supply Class

5315

Referenced on: http://binocularsandtelescopes.tpub.com//TM-9-1240-400-34-P/TM-9-1240-400-34-P0243.htm
Referenced on: http://binocularsandtelescopes.tpub.com//TM-9-1240-400-34-P/TM-9-1240-400-34-P0295.htm
Referenced on: http://binocularsandtelescopes.tpub.com//TM-9-1240-400-34-P/TM-9-1240-400-34-P0299.htm
Referenced on: http://binocularsandtelescopes.tpub.com//TM-9-1240-400-34-P/TM-9-1240-400-34-P0312.htm

Description

A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.

Commercial and Government Entity Code (Supplier Data)

---

54418

---

---

NSN (National Stock Number) 5315-00-807-7957, 5315008077957 NIIN (National Identification Number) 00-807-7957, 008077957

Part Numbers (Reference Numbers)

MS16555-608
M195-265

Required Categories

MATERIAL
MATERIAL DOCUMENT AND CLASSIFICATION
SURFACE TREATMENT
SURFACE TREAT

Required Description

STEEL COMP 410 OR
STEEL COMP 416 OVERALL
ASTM A493 ASSN STD 1ST MATERIAL RESPO
