National Item Identification Number
00-472-1954
National Stock Number
Item Name
PIN,STRAIGHT,HEADLESS
Federal Supply Class
5315
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-261-24P/css/TM-9-2350-261-24P_1143.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-261-24P/css/TM-9-2350-261-24P_1300.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-261-24P/css/TM-9-2350-261-24P_1429.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-277-24P/css/TM-9-2350-277-24P_1114.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-277-24P/css/TM-9-2350-277-24P_1269.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-277-24P/css/TM-9-2350-277-24P_1408.htmDescription
A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.
Commercial and Government Entity Code (Supplier Data)
19207
NSN (National Stock Number) 5315-00-472-1954, 5315004721954 NIIN (National Identification Number) 00-472-1954, 004721954
Part Numbers (Reference Numbers)
11647454
Required Categories
MATERIAL
SURFACE TREATMENT
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION
FIRS
Required Description
STEEL OVERALL
CADMIUM OVERALL
QQ-P-416,TY 2,CL 3 FED SPEC SINGLE TREATMENT RES
